EVA HIGH VOLTAGE INSULATING BLANKET

INSULATING BLANKET

EVA HIGH VOLTAGE INSULATING BLANKET

The INSULATING BLANKET are used as a portable protective device for protection of electrical workers from accidental contact with live electrical conductors, apparatus, or circuits. The insulating blankets are light and easy to use compared to rubber insulating products. Features: ・Lightweight ・Flexbile and good workability ・Equivalent to rubber insulating blanket in voltage proof test

Description

SIZEA.C. PROOF TEST VOLTAGEA.C. MAXIMUM USAGE VOLTAGE
600 × 100030kV/3min26.5kV
680 × 80030kV/3min26.5kV
680 × 120030kV/3min26.5kV
800 × 100030kV/3min26.5kV
900 × 100030kV/3min26.5kV
600 × 100020kV/3min17kV
680 × 80020kV/3min17kV
680 × 120020kV/3min17kV
800 × 100020kV/3min17kV
900 × 100020kV/3min17kV
